Air Sampling Smoke Detector - FF ASD

FEATURES

  • Color LCD display
  • User-friendly interface
  • 3 different sensitivity settings
  • Reliable and early detection technology with high sensitivity
  • Operates under harsh environmental conditions (high temperature, humidity, electromagnetic radiation, etc.)
  • Adjustable alarm delay
  • Clog detection technology thanks to air flow monitoring feature
  • Separate status indicator for each channel
  • Independent detection on each channel via two separate sensors
  • Each sensor has 2 alarm levels (Pre-alarm, Alarm)
  • Adjustable alarm delay feature (0-99 seconds)
  • "Self-study" function optimizes threshold values according to environmental conditions

Power Supply Voltage 24V DC (20-28V DC)
Operating / Alarm Current <1.8A / <2.2A
Relay Output Capacity 1A / 24V DC or 1A / 120V AC
Operating Temperature -10°C to +55°C
Dimensions 290 x 125 x 350 mm
Weight 4.5 Kg
Relative Humidity 10-95% (Non-condens
DATA SHEET
